Description
The Reference Audio Hydra 12.2 XL is an extreme high-performance 12-inch DVC subwoofer engineered for serious bass enthusiasts and competition-level car audio systems. It delivers massive low-frequency output, aggressive bass response and exceptional power handling for demanding applications.
Additionally, the Hydra 12.2 XL features a cast aluminium basket, fibreglass compound cone and high-density foam surround for superior durability and cone control. Its massive motor structure and dual 2 Ohm voice coil configuration also make it ideal for high-output SQL and SPL builds.
4000W RMS power handling
Dual 2 Ohm voice coil configuration
Heavy-duty cast aluminium basket
Fibreglass compound cone design
High-density foam surround
PP dust cap
Massive 4″ black aluminium voice coil
Huge 488 oz ferrite magnet structure
4-layer black aluminium voice coil material
Extreme low-frequency performance
Designed for competition car audio systems
Specifications
Product Name: Reference Audio Hydra 12.2 XL
Subwoofer Size: 12″
Subwoofer Type: DVC Subwoofer
Nominal Power Rating: 4000W RMS
Sensitivity: 86 dB
Frequency Response: 40 Hz – 500 Hz
Impedance: Dual 2 Ohm
DC Resistance: 2 x 1.8 Ohm
Cone Material: Fibreglass Compound
Basket Material: Cast Aluminium
Surround Material: High-Density Foam
Dust Cap Material: PP Dust Cap
Voice Coil Diameter: 100 mm
Voice Coil Height: 70 mm
Voice Coil Material: 4-Layer Black Aluminium
Magnetic Gap Height: 25 mm
Magnet Structure: 488 oz Ferrite
Voice Coil Configuration: Dual Voice Coil (DVC)
Subwoofer Dimensions: 323 x 255 mm
Mounting Depth: 239 mm
